A home theater system to meet your needs: budget, style and space!

System includes:

5 x Cinema 100 Satellite Speaker
1 x Cinema Sub

Overview

When size and sound matter

While it’s true, there are tiny satellite speakers aided by small subwoofers that can be “hidden” in many living spaces, when it comes to great audiophile sound these systems had never delivered … until Cinema. For years now, our award-winning Cinema speakers have been delivering a seamless music and home theater soundstage that brings movies to life and makes music sound “live.”

Also, there is a stand-alone Cinema Sub available to deliver those deeper, dynamic special effects … purpose-built with high SPL’s to support the lower octaves. But that’s not all! Cinema Sub is musical, offers excellent pitch definition, terrific transient response without sacrificing slam and impact.

Rumour has it that with this new generation of Cinema speakers, sound may be even better than the movie.

Cinema™ 100:

Superior S-PAL™ Satin-Anodized Pure-Aluminum Bass/Midrange Cones with advanced motor structures and powerful ceramic / ferrite magnets. The additional mica mineral content stiffened cone composition. Sound reproduction is particularly detailed providing clear and natural sounding vocals and crisply audible movie dialog.

Superior Mineral-Filled Polypropylene Bass Cones with magnet structures tweaked for performance to deliver solid, extended bass performance.

Superior S-PAL™ Satin-Anodized Pure-Aluminum Domes with powerful neodymium magnets and ferro-fluid cooling for increased power handling! Highs are transparent with a superb sense of air and exceptional spaciousness.

Wire Mesh Tweeter Guard and WaveGuide™ technology ensure a smooth, wide panorama of audiophile-quality sound.

Reference quality crossovers in an affordable audiophile … almost unheard of! Driver integration is virtually seamless across the full range of frequencies.

Push-thru Binding Posts with Easy-Glide™ Channels.

Cinema™ Sub:

Superior 8˝ High-Excursion Driver made of a durable reinforced polymer composite that in concert with the superior suspension system and motor/magnet structure allow the cone to travel farther while maintaining effective control.

Built-In High-Current, Discrete Output Amplifier: 300 watts Dynamic Peak / 100 watts RMS Sustained.

Dual Ported Design for even and articulate response.

Amplifier Controls:

Auto On / Standby / Soft Clipping
Subwoofer Cut-Off Frequency
Sub / Sat Phase Switch – 0° or 180°

Inputs:

Two, line level

Two aesthetic placement options … gloss side up or cloth side up. Includes four easy-to-install feet.

Specifications

Cinema™ 100 SPECIFICATIONS
Design	2-driver, 2-way acoustic suspension, mineral-filled polymer enclosure
Crossover	2nd-order electro-acoustic at 1.8 kHz
High-Frequency Driver	25-mm (1 in) S-PAL™ dome tweeter, ferro-fluid damped and cooled
Bass / Midrange Driver	102-mm (4 in) mineral-filled polypropylene cone, 25-mm (1 in) high-temperature voice coil, advanced motor structures and oversized ferrite magnets
Low-Frequency Extension*	85 Hz (DIN)
Frequency Response: On-Axis 30° Off-Axis	±2 dB from 125 Hz - 20 kHz ±2 dB from 125 Hz - 15 kHz
Sensitivity - Room / Anechoic	88 dB / 85 dB
Suitable Amplifier Power Range	15 - 100 watts
Maximum Input Power†	50 watts
Impedance	Compatible with 8 ohms
Height, Width, Depth	21.2 cm x 12.2 cm x 15.7 cm 8-3/8 in x 4-13/16 in x 6-13/16 in
Weight (unpacked)	1.8 kg / 4.0 lb each
Finishes	Black Gloss
Paradigm Stand (sold sep.)	MC-30

* DIN 45 500. Indicates -3 dB in a typical listening room.

† With typical program source, provided the amplifier clips
no more than 10% of the time.

Cinema™ Sub SPECIFICATIONS
Design	Single driver, bass reflex, high-velocity low-turbulence resitive ports, built-in amplifier, flexible positioning: gloss side up or cloth side up with feet
Amplifier High-Current Discrete Output	300 watts Dynamic Peak 100 watts RMS Sustained
Amplifier Features	Auto-on; standby; soft clipping
Bass Driver	210-mm (8 in) high-excursion reinforced co-polymer
Low-Frequency Extension*	32 Hz (DIN)
Subwoofer Cut-Off Frequency	Variable 35 Hz – 150 Hz; bypass option
Sub / Sat Phase Switch	Variable 0° or 180°
Line-Level Input	Two RCA (L/R-Mono) for L/R lineout or Sub-Out/LFE-Out of receiver/processor or other line-level source
Line-Level Input Impedance	10k ohms
Height, Width, Depth (gloss side up, height is with feet)	Compatible with 8 ohms
Height, Width, Depth	34.2 cm x 32.2 cm x 32.2 cm; 13-7/16 in x 12-11/6 in x 12-11/16 in
Weight (unpacked)	9.7 kg / 21.4 lb
Finishes	Black Gloss, Black cloth
